LD-CLD 3.0 Drone cigarette dispenser


This product is a 38mm caliber color cigarette dispenser for unmanned aerial vehicles, developed based on the Xinjiang OSDK and suitable for the Xinjiang M300RTK flight platform. It is compatible with various types of ammunition. Adopting a modular quick disassembly design, easy and fast disassembly, OSDK link control, APP floating window operation, without the need for additional remote control hardware, single person can control, and other signal modes can be selected according to actual task situations. Support the joint operation of drones with single and dual PTZ, making the operation more efficient. The 38mm caliber 6 power generation percussion bomb has the capacity to load Smoke grenade, Tear gas, shock detonation bomb and other ammunition, and is suitable for military, anti-terrorism, fire fighting, rescue, drill and emergency events.

Product Introduction





◆ Appearance design

The overall use of aviation aluminum material, CNC processing technology manufacturing, anodizing treatment; High precision, sturdy and reliable, strong resistance to electromagnetic interference, corrosion resistance, and wear resistance. Industrial style design, with a strong sense of thickness and aesthetics.





◆ Mechanical design, safety and stability

The vertical launch reduces unnecessary vulnerable structures, and the design is more consistent with Structural mechanics. It is especially suitable for multi rotor UAVs, and can significantly reduce the impact of the rear seat force oscillation of the cigarette dispenser on the flight stability of UAVs.





◆ OSDK+APP Simple

The communication method of DJI OSDK achieves control channel integration, and is installed in the M300RTK remote control with a dedicated app. No additional third-party remote control hardware is required, and the control distance is no longer limited, allowing a single person to control and execute tasks.

Other signal modes can also be selected according to the actual situation of the customer.





◆ Convenient power supply method

Insert the power supply equipment end connector into the power supply port of the cigarette dispenser, and the body end connector into the OSDK interface on the top of the aircraft to complete the power supply connection (M300 power plug with anti reverse insertion design).





◆ Quick disassembly and unloading

The design of sliding card slot and spring lock catch enables quick mounting. Installation only requires a gentle push of the spring lock catch to lock the cigarette dispenser, achieving dual protection, safety and reliability. Simply press the spring lock and gently push the cigarette dispenser to remove it, making it convenient and fast. When loading ammunition, pull the pull ring type buckle, lift it upwards to quickly load the ammunition, and lightly press to lock the magazine.





◆ Design of detachable and quick dismantling hanging rack

Precise measurement and precise design perfectly fit the M300RTK casing, allowing for quick disassembly of the rack without the need to disassemble it, which can be placed in the aviation box with the drone.

The high-precision universal design of the quick dismantling hanger can be used on the same platform as other modules of our company. The material is made of aviation aluminum through CNC processing technology and sandblasting anodizing treatment, which has the advantages of high precision, high strength, anti-corrosion, and wear resistance.





◆ Technical Parameter



Overall dimensions 155mm*147mm*159mm
Outer packaging box 382mm*300mm*192mm
Net weight 1.10 KG
Material quality Aviation aluminum
Installation method Quick release type
Launch method Electric shock
Caliber size 38 mm(Adaptation: recoil force 1-2kg, range 80m, electric shock fire)
Power supply mode Airborne OSDK interface power supply
Working voltage 24V
Loading capacity 6 pieces
Control mode OSDK communication APP control
Controlling Distance Consistent communication distance with M300RTK
Control angle Vertical
Application M300RTK(Other autonomous models, please contact sales first)





◆ Module application scenarios





This product has a wide range of applications, including military, counter-terrorism, firefighting, rescue, exercises, dispersal of illegal gatherings, mass riots, and other unexpected events.

Six standard 38mm electric shock ammunition can be attached, and Tear gas, detonation bomb, Smoke grenade, Stun grenade, dazzle bomb, etc. can be selected.
