LD-SOVO-5100 High definition emergency control ball


The 4G high-definition control ball adopts an integrated solution that integrates modules such as wireless video transmission, high-definition cameras, video storage, and high-capacity lithium batteries. It has a compact structure and high reliability, and can fully meet the needs of emergency temporary control and vehicular mobile monitoring. It is widely used in high-definition video emergency command industries such as power, fire protection, public security, and so on.

图片名称

Accessories:

Product Introduction

◆ Integrated Design

Built in large capacity lithium battery, ultra long endurance, independent LED screen displays integrated working status; Dual TF card storage, capable of supporting 64G; Highly integrated 4G antenna, WIFI antenna, Bluetooth antenna, GPS/BD antenna; Audio output supports high-power handheld microphones; The protection level can reach IP66.





◆ Efficient network transmission

Support dual card 4G all network connection bundled transmission or 4G public network+4G private network mixed network transmission; Equipped with a built-in WIFI module, videos can be previewed directly on mobile phones and tablets, and mobile tablets can also access the internet through a ball player.





◆ Powerful zoom camera

33X optical zoom, 12x digital zoom; 1/2.8 ″ 2.41 million pixel Progressive scan high-performance CMOS sensor is adopted, with a maximum resolution of 1080P; The infrared irradiation distance can reach 60 meters, enabling day and night monitoring.





◆ Design of magnetic composite suction cups

The bottom is equipped with a high suction magnet, which is fast to install and easy to deploy. The device can be quickly temporarily placed in a location that needs to be monitored, or on a telescopic tripod, or directly attached to a car. It is convenient to remove the device at the end of the task. Optional multi-functional chassis (wall mounted, pole mounted, and other fixing methods)





◆ Technical Parameter



Camera

Imaging device

Effective pixels

scanning system

Minimum illumination

Flat resolution

Noise ratio

Progressive scan IMX222-1/2.8 "high-performance CMOS sensor

2.41M pixels

Progressive scan

Color: 0.05Lux, black and white: 0.005Lux (F1.6)

≥ 1200TVL

>50dB

Shot

focal length

visual angle

Minimum object distance

4.6 * -153mm 33X optical, 12x digital zoom

Approximately 66.1 ° (W) * -2.46 ° (T)

Wide 20mm, Tele 1m

Function

Horizontal pan head

Vertical pan tilt

Cruise scanning

Preset

360 ° continuous rotation, 120 °/s

-20 ° -90 ° rotation, 80 °/s

4 articles

200

Display
LED Support status information display
Audio frequency

Audio compression

Intercom

AMR/G711

Support hand microphone

Positioning
Satellite Built-in Beidou/GPS, antenna built-in
Infrared

Irradiation distance

IR LED Quantity

60 meters (850nm)

4 pieces

Battery
Battery Built-in 13.6Ah lithium battery, sustainable operation for 6-8 hours
Support DC12V voltage input, equipped with charger 12.6V 3A
Network

network interface

4G/3G

WIFI

resolving power

video compression

Network Protocol

10/100M RJ45 interface

2 card 4G all network connection bundled transmission, or 4G public network+4G private network mixed network transmission

Support 802.1b/g/n; Can be operated using mobile phones and tablets

1080P/25 frames

H. 265/H.264

TCP/IP, HTTP, DHCP, DNS, RTP/RTCP, RTSP, PPPOE

Storage
TF Supports 2 TF interfaces, push type
SD card storage, with a maximum capacity of 128G per card, automatic cyclic coverage
General specifications

power dissipation

working temperature

Protection level

Installation method

size

weight

Normal 15W/25W full load

-20-60 °

IP66

Composite magnetic suction cup, fixed bracket

160 * 238 (H)

2KG (equipment)





◆ Application scope

Suitable for industry applications such as field law enforcement, investigation and control, security, emergency command, preemptive repair, and patrol management, such as public security, traffic police, firefighting, road administration, urban management, courts, prisons, forestry, electricity, water conservancy, environmental protection, etc.
